Surly Bikes
Moonlander
Moonlander
Regular price
$2,999.00 USD
Regular price
Sale price
$2,999.00 USD
Unit price
/
per
Couldn't load pickup availability
| SIZE | Small (16) | Medium (18) | Large (20) | xLarge (22) | xxLarge (22L) |
|---|---|---|---|---|---|
| Reach | 397.7 | 414.8 | 429.0 | 438.3 | 448.9 |
| Stack | 580.1 | 589.5 | 608.3 | 627.2 | 641.3 |
| Head Tube Angle | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| Head Tube Length | 110.0 | 120.0 | 140.0 | 160.0 | 175.0 |
| Seat Tube Length | 406.4 | 457.2 | 508.0 | 558.8 | 558.8 |
| BB Drop | 60.0 | 60.0 | 60.0 | 60.0 | 60.0 |
| Wheelbase | 1073.4 | 1093.9 | 1114.8 | 1130.7 | 1146.4 |
| Chainstay Length | 450.0 | 450.0 | 450.0 | 450.0 | 450.0 |
| Top Tube Length, Actual | 555.2 | 570.8 | 590.2 | 607.3 | 620.6 |
| Top Tube Length, Effective | 575.0 | 595.5 | 615.0 | 630.0 | 645.0 |
| Seat Tube Angle | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
| Standover Height | 771.1 | 800.1 | 833.8 | 868.0 | 875.0 |
| Fork Length | 447.0 | 447.0 | 447.0 | 447.0 | 447.0 |
| Fork Rake | 43.0 | 43.0 | 43.0 | 43.0 | 43.0 |
